Specification
|
Processor |
Microprocessor (ARM Cortex M7 400MHz) |
|
Storage |
128MB NAND flash memory & SD Card |
|
Analog |
24bit SAR |
|
Power Output |
12V (100mA) * 3port |
|
Power |
12V DC |
|
Power Consumption |
400 mA |
|
Operating Environment |
-40 ℃ ~ +80 ℃ |
|
Dimensions |
248 × 138 × 45 (mm) |
|
Weight |
0.62 kg |
Interface
|
Wireless Interface |
WIFI(option) |
|
Wired Interface |
10/100Mb Ethernet * 1port |
|
USB 2.0 * 1port | |
|
Console(Type-C) * 1port | |
|
RS-232 * 4port | |
|
RS-422/485 * 1port | |
|
Analog Interface |
AD Converter(0~2.5V) Single * 16port, Differential * 8port |
|
DA Converter(2.5V) * 2port | |
|
Excitation Channel * 6port (RTD temperature measurement) | |
|
Digital Interface |
Digital Input * 4port |
|
SDI-12 * 1port | |
|
CAN * 1port | |
|
Frequency Channel |
Frequency Counter * 4port |
