Specification
Processor | Microprocessor (ARM Cortex M4) |
Storage | 128MB NAND flash memory |
Analog | 24bit SAR |
Power Output | 12V (100mA) * 2port |
Power | 12V DC |
Power Consumption | 50 mA |
Operating Environment | -40 ℃ ~ +80 ℃ |
Dimensions | 188 × 118 × 44 (mm) |
Weight | 0.59 kg |
Interface
|
Wired Interface |
10/100Mb Ethernet * 1port |
|
Console(Micro 5Pin) * 1port | |
|
RS-232 * 3port | |
|
RS-422/485 * 1port | |
|
Analog Interface |
AD Converter(0~2.5V) Single * 16port, Differential * 8port |
|
DA Converter(2.5V) * 2port | |
|
Excitation Channel * 8port (RTD temperature measurement) | |
|
Digital Interface |
Digital Input * 4port |
|
SDI-12 * 1port | |
|
CAN * 1port | |
|
Frequency Channel |
Frequency Counter * 3port |
