Specification
Processor | Microprocessor (ARM Cortex M4) |
Storage | 128MB NAND flash memory |
Analog | 24bit SAR |
Power Output | 12V (100mA) * 2port |
Power | 12V DC |
Power Consumption | 50 mA |
Operating Environment | -40 ℃ ~ +80 ℃ |
Dimensions | 240 × 88 × 36 (mm) |
Weight | 0.57 kg |
Interface
Wired Interface | 10/100Mb Ethernet * 1port |
Console(Type C) * 1port | |
RS-232(CAN port combined) * 3port | |
RS-422/485 * 1port | |
Analog Interface | AD Converter(0~2.5V) Single * 8port, Differential * 4port |
Excitation Channel * 1port (RTD temperature measurement) | |
Digital Interface | Digital Input * 2port |
SDI-12 * 1port | |
CAN * 1port | |
Frequency Channel | Frequency Counter * 2port |
