Specification
|
RH(CH1) |
Temp.(CH2) | |
|
Measuring Method |
Capacitive Polymer |
PT1000 |
|
Measuring Range |
0 ~ 100%rh |
-40 ~ 80℃ |
|
Accuracy |
± 2%rh (0~98%rh) |
±0.3℃ (Class B) |
|
Resolution |
0.1%rh |
0.1℃ |
|
Response time |
< 6sec (50%rh → 0%rh @23℃) |
< 6sec (@ 1m/s) |
|
Response time |
0 ~ 1V | |
|
Operation Temperature |
-50 ~ 60℃ | |
